    Product Features
    1. long workinfe life .50000working hours

    2. various application , can be used in different LED lighting project ,especially for industrial light

    3. best material , we choose the best raw material ,the 6063 Aluminium is one of the best material for heat dissipiation to ensure the working life of the module light

    4. Cree chip .140lm/Watt

    LED module light parameters
    Applications
    Specification
    Model Power Input voltage Light Efficiency CCT CRI LED Lifetime Product Size Carton Size
    ASL50-1M 30W/40W/50W/60W AC85-265V 120-130Lm/W 2700-6500k ≧70 >50000h 680*320*105mm 695*335*120mm
    ASL50-2M 60W/80W/100W/120W AC85-265V 120-130Lm/W 2700-6500k ≧70 >50000h 680*320*105mm 695*335*120mm
    ASL50-3M 90W/120W/150W/180W AC85-265V 120-130Lm/W 2700-6500k ≧70 >50000h 680*320*105mm 695*335*120mm
    ASL50-4M 120W/150W/200W/240W AC85-265V 120-130Lm/W 2700-6500k ≧70 >50000h 920*380*143mm 935*395*160mm
    ASL50-5M 150W/200W/250W/300W AC85-265V 120-130Lm/W 2700-6500k ≧70 >50000h 935*395*160mm 935*395*160mm
