    Product Features
    Modern fashion design of appearance,made the light become an artwork,integrated with the environment perfectly,to made is as top project
    Die-cast aluminum body with powder-coating and anti-corrosion treatment
    Excellent heat radiation,optical and electrical ability
    Two type led chips and four type led drivers for choose
    Luminaire available from 60-200W
    Inpute Voltage:AC90-305V,50/60Hz.IP65,IK09
    5 years warranty
    Applications
    street, road, park,and ...
    Specification
    Model Power LED Qty Light Distribution Input voltage Light Efficiency Power Factor CCT CRI LED Lifetime N.W G.W Product Size Carton Size
    ASL08A
    15W 3030,16pcs 120º*60º AC85-265V 120-130Lm/W >0.95 2700-6500k ≧70 >50000h 4.5kg 5kg 573*220*131mm 655*300*210mm
    25W 3030,32pcs 120º*60º AC85-265V 120-130Lm/W >0.95 2700-6500k ≧70 >50000h 4.5kg 5kg 573*220*131mm 655*300*210mm
    35W 3030,40pcs 120º*60º AC85-265V 120-130Lm/W >0.95 2700-6500k ≧70 >50000h 4.5kg 5kg 573*220*131mm 655*300*210mm
    45W 3030,48pcs 120º*60º AC85-265V 120-130Lm/W >0.95 2700-6500k ≧70 >50000h 4.5kg 5kg 573*220*131mm 655*300*210mm
    ASL08B 60W 3030.64pcs 120º*60º AC85-265V 120-130Lm/W >0.95 2700-6500k ≧70 >50000h 8.5kg 9kg 664*251*132mm 725*330*210mm
    90W 3030,96pcs 120º*60º AC85-265V 120-130Lm/W >0.95 2700-6500k ≧70 >50000h 8.5kg 9kg 664*251*132mm 725*330*210mm
    ASL08C
    120W 3030,124pcs 120º*60º AC85-265V 120-130Lm/W >0.95 2700-6500k ≧70 >50000h 10.5kg 12kg 740*285*132mm 820*365*210mm
    200W 3030,256pcs 120º*60º AC85-265V 120-130Lm/W >0.95 2700-6500k ≧70 >50000h 10.5kg 12kg 740*285*132mm 820*365*210mm
    250W 3030,298pcs 120º*60º AC85-265V 120-130Lm/W >0.95 2700-6500k ≧70 >50000h 10.5kg 12kg 740*285*132mm 820*365*210mm
