Product Features

Modern fashion design of appearance,made the light become an artwork,integrated with the environment perfectly,to made is as top project
Die-cast aluminum body with powder-coating and anti-corrosion treatment
Excellent heat radiation,optical and electrical ability
Two type led chips and four type led drivers for choose
Luminaire available from 60-200W
Inpute Voltage:AC90-305V,50/60Hz.IP65,IK09
5 years warranty

Applications

Specification

Item NO.	Power	Lumen	Product Size	LED Chip 3030 1W	Main Material	LED Driver	Color Temperature	IP Grade	Input Voltage	Package information
										Carton size	Pc/Ctn
ASL03B-120W	120W	100-130lm/w	739308207mm	Philips 3030 192PCS	Die Cast Aluminum	Inventronics	3000K-6500K	IP65	AC 90-305V	754323222mm	1
ASL03B-150W	150W		739308207mm	Philips 3030 192PCS	Die Cast Aluminum	Inventronics	3000K-6500K	IP65		754323222mm	1
ASL03B-200W	200W		739308207mm	Philips 3030 256PCS	Die Cast Aluminum	Inventronics	3000K-6500K	IP65		754323222mm	1
