    Product Features
    1、Chip imported from taiwan. low power consumption, high efficiency, long service life.
    2、Body material:high quality aluminum die casting, corrosion resistant, anti-cracking. non fading color by stoving varnish.
    3、High purity aluminum radiator, severe convection design ensures excellent heat dissipation and long light source service life.
    4、High strength toughened glass with good transparency.
    5、Casting glue ensures excellent waterproof performance of driver, intelligent control circuit. overvoltage and undervoltage protection.
    6、Environmental protection, (no pollution tno lead & mercuryl), no radiation. favorable to recycle.
    Applications
    1、Widely used in building facades, plaza, garden landscape, golf courses, villas, farms and other outdoor places.
    Specification
    Model No. Power Size(L*W*H)
    (mm)
    Input
    Voltage
    Luminous Efficacy
    (lm/w)
    Power
    Factor
    Color
    Temperature
    CRI(Ra) Beam
    Angle
    IP Grade Life Span
    AF08-10W 10W 130*110*40 AC 85-265V 80-90Lm/W >0.9 2700-7000K >70 120° 65 >50000Hrs
    AF08-20W 20W 180*150*50 AC 85-265V 80-90Lm/W >0.9 2700-7000K >70 120° 65 >50000Hrs
    AF08-30W 30W 225*190*60 AC 85-265V 80-90Lm/W >0.9 2700-7000K >70 120° 65 >50000Hrs
    AF08-50W 50W 280*235*69 AC 85-265V 80-90Lm/W >0.9 2700-7000K >70 120° 65 >50000Hrs
    AF08-100W 100W 370*310*84 AC 85-265V 80-90Lm/W >0.9 2700-7000K >70 120° 65 >50000Hrs
    AF08-200W 200W 450*380*122 AC 85-265V 80-90Lm/W >0.9 2700-7000K >70 120° 65 >50000Hrs
