    Product Features
    1.LED type:4014 SMD
    2.Material:Alu+PMMA L.G.P.+PMMA Diffuser
    3.Guarantee:3 years
    Applications
    Specification
    Model  Voltage Power Lumens(LM) Ra Color Temperature Beam Angle Lamp Size(mm) Qty/ctn Packing Size(mm)
    APDS24R/24S AC90-260V 24W 2400 >70 3000-6000K 120° Φ240*40/240*40 20 435*270*530
    APDS16R/16S AC90-260V 16W 1440 >70 3000-6000K 120° Φ190*40/190*40 20 435*220*430
    APDS9R/9S AC90-260V 9W 810 >70 3000-6000K 120° Φ145*40/145*40 40 435*335*350
    APDS5R/5S AC90-260V 5W 450 >70 3000-6000K 120° Φ105*40/105*40 60 435*255*420
