    Product Features
    1.LED type:2835 SMD
    2.Work temperature:-25℃—50℃
    3.Guarantee:2 years
    4.Material:PC
    Applications
    Size Chart
    Specification
    Model  Voltage Power Lumens(LM) Ra Color Temperature Beam Angle Size(mm) Qty/ctn Packing Size(mm)
    AC03-18W AC110/220V 18W 1260 >80 2700-6500K 160° Φ310*50mm 12  660*335*445
    AC03-15W AC110/220V 15W 1050 >80 2700-6500K 160° Φ250*45mm 12 540*275*395
    AC03-13W AC110/220V 13W 910 >80 2700-6500K 160° Φ210*40mm 12 460*235*365
    AC03-8W AC110/220V 8W 560 >80 2700-6500K 160° Φ155*35mm 12  340*175*320
    AC03-5W AC110/220V 5W 350 >80 2700-6500K 160° Φ155*35mm 12  340*175*320
    AC03-18W-S AC110/220V 18W 1260 >80 2700-6500K 160° Φ310*58mm 12  660*335*445
    AC03-15W-S AC110/220V 15W 1050 >80 2700-6500K 160° Φ250*50mm 12 540*275*395
    AC03-13W-S AC110/220V 13W 910 >80 2700-6500K 160° Φ210*43mm 12 460*235*365
    AC03-8W-S AC110/220V 8W 560 >80 2700-6500K 160° Φ155*40mm 12  340*175*320
    AC03-5W-S AC110/220V 5W 350 >80 2700-6500K 160° Φ155*40mm 12  340*175*320
